Warmehaus Convector Radiator Double Panel Type 22 H400 x W600mm

Type 22 H400 x W600mm Compact Double Convector Radiator
The Type 22 H400 x W600mm Compact Double Convector Radiator is the perfect solution for space saving with quality guaranteed. Manufactured using modern technology, this compact radiator will deliver the maximum efficiency. All radiators come complete with top grille and side panels already assembled. This compact radiator comes with a 10-year guarantee against faulty manufacture.

Features and Benefits:
400mm x 600mm x 105mm
2324 BTU's (681 Watts)
White powder coat finish
10 Year Guarantee
Tested and Certified to BS EN 442 Standards
CE Marked
Includes top grille and side panels already assembled

Dimensions and Specifications:
Heat Output Watt T30: 352
Heat Output BTU T30: 1204
Heat Output Watt T50: 681
Heat Output BTU T50: 2324
Heat Output Watt T60: 861
Heat Output BTU T60: 2939
Height: 400mm
Width: 600mm
Depth: 105mm
Overall Projection from Wall: 135/150mm
Horizontal Pipe centre: 670mm (approx.)
Vertical Pipe centre: 345mm
Wall to Centre Tapping: 82.5/97.5
Material: Steel
Colour: White (RAL 9016)
Installation Type: Central Heating
Finish: Powder Coated
10 year "fit and forget" Guarantee Included
Fixing pack included complete with plugs and vents
Maximum Operating Pressure: 10 bar
Inlet Connection: 1/2"
CE, EN 442 Certified

Important Details:
We suggest you ask a qualified plumber to install this item
Excludes: Valves
Notice: The P&P is only for those addresses in Mainland England. A surcharge will apply to the remote areas.
