WiFi Air Conditioner Thermostat 5+2 Days 6 Periods, Programmable Central Air Conditioning Temperature Controller, White
Of which environmental contribution £0.10 including VAT.
Sold by Cuizi
Product information
Description
General Description
This WiFi central air conditioning thermostat is designed for efficient temperature control with an LED panel. It allows for energy savings and is compatible with the RTU protocol via a 485 interface. Its user-friendly design includes an illuminated temperature control knob and large touch buttons for easy operation.Technical Specifications
- Item Type: WiFi Air Conditioner Thermostat
- Housing Material: PC, ABS (Flame Retardant)
- Model: BAC-009ELW
- Fan Relay Amperage Resistance: 5A
- Inductance: 3A
- Valve Relay Amperage Resistance: 3A
- Inductance: 1A
- Sensor: Negative Temperature Coefficient 3950, 10k
- Temperature Range Setting: 5-35℃
- Accuracy: ±1℃
- Display Temperature Range: 5-99°C
- Ambient Temperature: 0-45°C
- Ambient Humidity: 5-95% RH (non-condensing)
- Mounting Box Dimensions: 86 x 86 mm (square) or 60 mm (round)
- Metal Terminal: 2 x 1.5 mm² or 1 x 2.5 mm² wire
- Protection Rating: IP20
- WiFi: 2.4 GHz WiFi
Compatibility and Accessories
- Installation in an 86 x 86 mm square box or a 60 mm round box
Installation
- Follow the instruction manual after removing the product for proper installation.
Usage
- This The thermostat is designed for use with 4-hose air conditioners only.
Other Information
- The button features 8 lighting effects and 7 color light transitions, including a Christmas light mode.
- Control panel thickness: 12.4 mm.
Features
- BrandOTHERS
- Length15 cm
- Width15 cm
- Height35 cm
- Weight2 kg
Advice from
Thermostat buying guide
Thermostats are used to control the temperature of a heating or cooling system to suit the occupant's lifestyle. In addition to making the home more comfortable, a thermostat can help you save on your energy bill. From various models and technologies to extra features, read on to find the best thermostat for your home.
