150W 12V RV Mono SOLAR PANEL Ideal for bonding to the Roof No need for drilling

Product out of stock
Secure Payment
Good to know
Return within 14 days












Product details
Features
  • Voltage
    12 V
  • Power
    150 W
  • productRef
    ME13795854
  • manufacturerSKU
    L02M150N-CWT-1
Description

"

Here for sale is off grid solar home system kit consist of 150W mono solar panel, 20A LCD solar charger controller and a whole set solar panel ABS plastic mounting bracket. We provide some panels for your reference. Those are hot items in ECO-WORTHY. With its high power output and perfect design for a solar system. Even on cloudy days, the panel still delivers a high power energy. The panel is covered with a special glass to protect against the bad environmental conditions suck as hail, snow and ice. And the panel frame is made of anodized aluminum to make the panel stability and durable.     For the solar panel mounting brackets. It is made of ABS plastic material. It is durable, stable and light. Easy for you to carry them and install for your RV motor home.     Package Includes: 1 pc 150W Mono Solar Panel
1 pc 20A Solar Controller
1 pair 5m Solar Cable
1 whole set mounting bracket:
(1x Cable entry, 2x Side Bracket, 4x Corner Bracket)       Specification:   150W Mono Solar Panel
Type150W Mono Panel
Rated power150W
Maximum/Peak Voltage(Vmp)16.6V
Open Circuit Voltage(Voc)20.3V
Maximum/Peak Current(Imp)9.04A
Short circuit current (Isc)9.61A
Output Tolerance±3%
Temperate coefficient of Isc(010+/- 0.01 ) %/°C
Temperate coefficient of Voc- (0.38 +/-0.01 ) %/°C
Temperate coefficient of power Voc-0.47%/°C
Temperature range-40°C to +80°C
FrameHeavy duty aluminum
Kind of glass and its thicknessLow Iron, high transparency tempered glass of 3.2mm
Size1315*665*35mm
      20A LCD Solar Charge Controller
MODELDZ-SCC-20
Battery voltage12V/24V auto
Charge current20A
Discharge current20A
Max Solar input<50V
Charge voltage13.7V
Discharge stop10.7V
Discharge reconnect12.6V
USB output5V/2A
Self-consume<15mA
Operating temperature-20°C - +60 °C
Size/Weight138*85*30mm /150g
Install hole size124*50mm
*all red color voltage X2 ,X4 while using 24V /48V system.



Solar Panel Bracket
- Ideal for bonding to the roof - no need for drilling
- Strong side support for small and large solar panels
- Great for motorhomes, campervans, caravans, lorries, buses, boats and yachts
- Can also be used on flat roofs of buildings, sheds, garages or other flat surfaces

Specifications

Corner Brackets:
Material: plastic
Colour: white
Size (1 bracket): 15 x15x6.5cm
Specifications: - side brackets
Material: plastic
Colour: white
Size (1 bracket): 18 x 9 x 6.5 cm
Specifications: -cable entry
Watertight cable entry for 4-12mm cables
Ideal for mounting solar panels on motorhomes, campervans, caravans or boats, buildings, garages, sheds and other roofs
Easily bonded to the surface using a suitable sealant
Material: plastic
Colour: white
Size: 12x10x5cm



1 pair MC4 with 5 meter 4mm²extension solar cable(5m red and 5m black)
For movable, suspended or fixed installation in photovoltaic systems at temperatures ranging from -40℃ to +120℃ For use indoors,outdoors,in explosive areas, and in industrial,commercial, and agricultural applications.

"

Questions & answers

All you need to know about this product from our experts
Can this panel charge the engine battery as well as the leisure battery bank?
It could charge both battery banks but obviously charge time would be slower.
Reviews
4,1/5
Overall rating out of 34 customer reviews
5
4
3
2
1
Average customer ratings
4.3
Value for money
(17 reviews)
Latest reviews
Guy.B.6224f4f257b83
1 April 2022
Good material quality / price Fast delivery compared to the said time, very satisfied
max-vi5
26 March 2022
To be connected to the motorhome so later deadlines and delivery all ok
handymano.6206b920a8cd2
2 March 2022
I bought this 150w system for my caravan as we plan on doing a bit of travelling this year. In my opinion it seems sturdy and well made. It was very easy to fit but I have a mechanical electrical background wiring is pretty straight forward even for the novice. Slightly harder was the fitting of the panel I chose to fix the panel to the brackets with a fairly hefty screw and then bonded the brackets to the caravan roof with silkka flex 522 as recommended by a friend who had fitted his using this. It has only been on a couple of days and the battery is fully charged so seems to be working great. At the moment I have not been away using the leisure battery so I have not been able to assess it’s ability to keep my battery charged when I am fully off grid but I am fairly confident that it will do a good job.
bricoleur.1897962
18 February 2022
good product my documents in French will be even better cordially
