John Guest Speedfit 22mm Black Acetal Stop End (Pack of 5) PM4622E

(£2.77/pcs)

You may also like

McAlpine V1MX-CO 1.5" Universal Slip TeeMCALPINE
#1 in sales

McAlpine V1MX-CO 1.5" Universal Slip Tee

Free delivery

Compare with similar items

Product information

Description

General description

John Guest 22MM Ring Main Stop End is designed to provide a permanent or temporary shut-off in compressed air systems. This push-fit system allows for quick and easy installation, minimizing the need for specialized staff and reducing production downtime. The connections are made with a simple push-in action, eliminating the need for preparing threaded pipes or solvents. The system is ready for immediate use and can be easily disconnected, altered, or extended.

Technical specifications

  • Body Material: Plastic
  • Diameter: 22mm
  • Operating Pressure: Up to 10bar
  • Operating Temperature Range: -20 to +70°C
  • Pipe Outer Diameter: 22mm
  • Maximum Torque Values:
  • Size 3/8: Plastic threads: 3.0Nm
  • Size 1/2: Metal threads: 4.0Nm
  • Size 3/4: Plastic threads: 4.0Nm, Metal threads: 5.0Nm
  • Size 1: Plastic threads: N/A, Metal threads: N/A
  • Tolerances: Size: 12mm to 28mm OD, Tolerance: +0.05 to -0.10mm OD
  • Compatibility and accessories

    Suitable for use with a wide range of plastic and soft metal pipes including UPVC, ABS, Polyethylene, nylon, mild steel, and copper. It is recommended to check all installations prior to use to ensure a proper seal has been made.

    Other information

    MPN: PM4622E
    EAN: 0665626113710
    John Guest 22MM Ring Main Stop End

    Features

    • Brand
      JOHN GUEST SPEEDFIT
    • Pressure
      10 bar
    • Material
      Plastic
    • Colour
      Black
    • Pipe thread size
      No pipe thread
