3/4 float valve, the water level control box is an improved version of the traditional float valve, used in swimming pools, livestock tanks, aquaculture and aquariums MUMU

Small size and easy to install: Float valve, estimated flow rate up to 40 psi (3 gallons per minute) to 60 psi (5 gallons per minute)

Automatic fill stop when filled: Float valve, automatic control, less filling water, water stop

Environmentally friendly: safe and does not release toxic substances.

Wide application: widely used in kettle machines, rice steamers, water tanks, water towers, toilet tanks, etc.

Buy without worries: We have confidence in this product, please contact us if it breaks. At the same time, since this product is an automatically movable valve, regular inspection and maintenance are required. Check the indicator before and every month to see if the valve turns on and closes normally.

Product Description

Dimensions: 3/4 white side.

Automatic valve float water level control valve.

Working pressure range: 1 - 10 kg (0.1 - 1 MPa).

Applicable medium: clean water.

Applicable average temperature: ≤70°.

Average high temperature: 10° ~ 70°

Type: vertical indoor installation.

Material: nylon + rubber.

Outlet diameter: 1/2 3/4 BSP thread.

Size: Please refer to the picture on the left to see the detailed picture.

Color as shown.

Working principle:

When the surface of the water tower or swimming pool sinks, the float flows in the valve chamber.

Use the hole pin to open the pilot hole of the control valve. Ascend, press the joystick to close the pilot hole, the valve cavity begins to fill with water, and then close the control valve. The sealing surface of the control valve immediately stops the water supply.

Package contents:

1 water level control valve

1 piece as shown.< /p>

Only the above package contents, other products are not included.

Notes:

This product is a liquid level control valve.

After installation, the float must be vertical. If you need to install from above, you will need an angle to connect the float valve and the inlet pipe. First, fix the water inlet pipe on a horizontal surface and then connect the automatic water level control valve to the water inlet according to the standard.

The main water inlet should be aligned with the normal diameter of the water control valve.

During operation, the shut-off valve must be fully open.

If two valves are installed in the same tank, they must be kept at the same level.

Clean any impurities in the pipe before installation to avoid blockages.
