35mm hinge jig, cabinet door hinge jig, concealed hinge jig, hole punch, drill guide locator for DIY woodworking

General Description

The 35mm hinge template is an essential tool for woodworking, allowing for precise and easy installation of concealed hinges on doors and cabinets. Made of aluminum alloy, it offers exceptional durability and convenient operation, requiring no professional skills.

Technical Specifications

• Material: Aluminum Alloy
• Hole Opener Diameter: 35 mm
• Adjustable Drilling Depth: 12-13 mm
• Adjustable Fixed Card Size: 15-25 mm
• Screw Hole Size: 2 mm

Installation

• Install the 35 mm hole opener.
• Adjust the drilling depth to 12-13 mm and lock the limit ring.
• Adjust the fixed size of the black pressure block on the quick-release clamp.
• Move the hole punch to the marked position and lock the quick-release clamp.
• Tighten the Drill handle and drill to a depth of 12-13 mm.
• Drill a 2 mm screw hole on the left and right sides.

Use

This jig is widely used to install most common hinges, making it easy to fit concealed hinges on your DIY projects.

Other information

• Package contents: Hinge drilling locator body x 1, 35 mm hole opener x 1, limit ring x 1, limit ring fixing screw x 1, wrench x 2, 2 mm drill bit x 1, hex bar wrench x 1.
