Hinge Jig 35mm, Door Cabinet Hinge Jig, Concealed Hinge Jig, Hole Punch, Drill Guide Locator for DIY Woodworking

Sold by B2C Agro Top Garden GmbH and 1 other seller

Product information

Description

General description

Our 35mm Hinge Jig is a precise and durable tool designed for DIY woodworking. Made from aluminum alloy, it ensures a long service life with accurate manufacturing and convenient operation. This jig is ideal for installing concealed hinges on doors and cabinets without the need for professional assistance.

Technical specifications

Material: Aluminum alloy

Drilling depth: 12-13mm

Adjustable fixed plate size: 15-25mm

Distance between 35mm hole and edge: 5mm

Installation

Install a 35mm hole opener.

Adjust the drilling depth to 12-13mm and lock the limit ring.

Adjust the fixed size of the black pressure block of the quick clamp.

Move the hole punch to the marked drilling position and lock the quick clamp.

Tighten the drill handle and press the hole to a depth of 12-13mm.

Drill a 2mm screw hole on the left and right.

Usage

This jig is commonly used for most standard hinges, making it a convenient tool for installing concealed hinges on various woodworking projects.

Other information

Package contents: Hinge Drill Locator Body*1, 35mm Hole Opener (with limit ring and fixed screw)*1, 2mm Drill Bit*1, Wrench*2, Hex Wrench*1.

Features

Brand
MEMKEY
Warranty
2 year(s)
Material
Aluminium
Pcs per pack
1
Colour
Black
