5.5KW VFD Variable Frequency Drive Three-Phase Frequency Inverter AC 380V to AC 0-380V Motor Control Inverter Voltage Converter

~~£340.13~~

Of which environmental contribution £0.01 including VAT.

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by LinzGain Sarl

Product information

Description

General description

The 5.5KW VFD Variable Frequency Drive is a three-phase frequency inverter designed to control AC motors from 0 to 380V. It features a robust copper core coil for high load capacity and stable performance. This inverter is ideal for various applications including fans, pumps, automatic machine tools, and engraving machines, offering high practicality in a compact design.

Technical specifications

Item Type: Frequency Inverter

Model: SKI7805D5G4

Material: PC, Aluminum

Applicable Motor: 5.5kW (7.5HP)

Input: AC3PH 380V ±15%, 15A, 47Hz-63Hz

Output: AC3PH 0V-380V, 13A, 0Hz-400Hz

Protection Class: IP20

Installation Height: Up to 1000 meters (3280 feet) above sea level

Ambient Operating Temperature: 0-40℃ (32-104℉)

Storage Temperature: -20-55℃ (-4-131℉)

Air Humidity: 5% to 85% during operation, non-condensing/non-freezing; 5% to 95% during storage

Compatibility and accessories

Package List: 1 Frequency Converter

1 User Manual

Installation

Pay attention to electrical safety during installation and use

If the installation height exceeds 1000 meters, reduce the current by 1.2% for every 10 meters (328 feet) of height

Usage

Supports VF control, vector control, and output torsion control

Integrated RS485 communication interface for stable connection with minimal interference

Features speed potentiometer and external panel with 6 speed control modes

Solid cooling fan design for effective heat dissipation

Features

Brand
SNQ
Voltage
380 V
Height
100 mm
IP rating
IP20
Nominal intensity
AC
Width
160 mm
Length
230 mm
Material
Aluminium
Weight
1500 g
Power
5500 W
ManoMano Reference
ME92565945
MMID
968579607619
Product code
FD-20257
EAN
6032223851491
