5m 250V 10A Float Switch for Submersible Pump Round
Of which environmental contribution £0.10 including VAT.
Sold by Cuizi
You may also like
Compare with similar items
Product information
Description
General description The 5m 250V 10A Float Switch for Submersible Pump is designed for effective monitoring of liquid levels in various applications. This float switch features a hollow design that is activated by the rising liquid, triggering a switch-on at an angle of +/- 50°. It is suitable for almost any pump and can be used to control pumps, valves, or alarm signals. Technical specifications Connection cable length: 5m Protection class: IP68 Voltage: 250V Frequency: 50/60Hz Max. switching angle: +/- 50° Operating temperature: up to 50°C Max. power: 10A Installation The float can be attached by screwing it to the side of the tank. If using an open tank, it can be placed from above on the liquid. For pumps with a power greater than 1.1 kW, a conventional relay or power contactor should be placed upstream. Usage This float switch is ideal for monitoring the fill level of any liquid that does not attack its material, regardless of the degree of contamination. It can be used as a full or empty indicator, and for controlling pumps or valves.
Features
- BrandOTHERS
- ColourWhite
- Intended useOutdoor
- ManoMano ReferenceME213175282
- MMID978636833584
