Aftermarket Replacement Starter Motor For Briggs And Stratton Ride On Mower 12v

About Starter

A starter (also self-starter, cranking motor, or starter motor) is a device used to rotate/crank an internal-combustion engine so as to initiate the engine's operation under its own power, located on the driver's side of the motor just down below the left bank of cylinders. There are a few bolts that hold it to the mounting plate that it is attached to.

Application

Starter Motor 12v replaces ride on mower

for Cub Cadet  1015   1988 - 1991

for Cub Cadet  1020  1988 - 1991

for Cub Cadet  1105  1985 - 1986

for Cub Cadet  111    1978 - 1979

for Cub Cadet  1110  1985 - 1986

for John Deere  111  1979 - 1985

for John Deere  111H  1982 - 1984

for John Deere  L118  -

for Toro  11-32  1978 - 1997

for Toro  11-38  1986 - 1987

for Toro  212-H  1989 - 1991

for Toro  825   1991

for Toro  LT12.5G   1995

for Toro  Sand Pro5000   1992 - 1993

OEM & Part Number:

394943, 399169, 490420, 494148,
494198, 494990, 497401, 499521, 499529, 691262, 795121
112563
BS-399169, BS-499521，
075255, 75255, 75255-A，
410-22005, 410-22015，
AM106883, AM38136, AM39285,
LG490420, LG497401, LG499521, LG691262, MIA11175, SE501860，
5746, 5778
STR-1005A，
78-4340，
49-5790，
 2-2191

Spcecification

Voltage : 12

Rotation : CCW

Starter Type : PMDD

Number of Teeth : 16

Gear OD : 1.598in / 40.6mm

Mtg Ear 1 Hole : 8.0mm Unthreaded

Mtg Ear 2 Hole : 8.0mm Unthreaded

Mtg Ear 3 Hole : 8.0mm Unthreaded

4.25"/108mm Long Field Case

Weight : 5.68 lbs / 2.58 kg

Mounting bolt spacing :  approx 58.5mm

Overall length:  approx 158.5mm(6.240")

Type:Lawnmower Starter;Lawn mower Starter motor

Feature

The new starter meets OEM specifications.
Sealed metal housing improves operating efficiency.
The performance is comparable to the original version.
Condition:  100% Brand New

Note

* Suits aluminium and plastic flywheel ring gears, will NOT suit steel gears
* Please check the number of gears and overall length, here is 16 teeth. We also sell  Starter Motor of 14 teeth.
* Please allow 1-2mm for variance due to manual measurement.
* Package Includes: You will get exactly as shown as picture above.
* Professional installation is highly recommended (No Instruction Included)
