AICA Thermostatic Chrome Bathroom Mixer Shower Set Square Exposed Valve

If you're looking for something that's stylish, practical and most importantly safe then the Aica Square Thermostatic Shower Valve and Riser System is the ideal addition to your bathroom.

It features a convenient handset which can be adjusted to suit a range of heights while also benefiting from a huge drencher head to really invigorate every pore first thing in the morning. The riser rail has adjustable fixing points allowing you to retrofit your old shower and the complete set is finished in a brilliant and high quality chrome.

The shower valve itself is constructed from solid brass for the best durability and reliability. This is of course thermostatically controlled for added safety meaning that water temperatures stay at the same level no matter what is going on elsewhere in the house.

Features and Benefits:

• Thermostatically Controlled Shower Valve Exposed иC Protecting the user from scalding when getting into the shower
• Separate Controls / Dual Handle; One For Flow Rate and determine use of Drencher Head or Handset and One For Temperature
• Solid Brass Thermostatically Controlled Shower Valve
• Chrome Plated Finish
• Stainless Steel Riser System
• 200mm x 200mm Drencher Head
• Chrome Finished Handset
• The shower mixer is made of high-quality brass, stainless steel, metal and plastic and is removable and washable.
• Adjustable holder for Handset which can be moved up and down the riser
• Adjustable Riser Rail to accommodate different installation requirements for the mounting points
• CE Approved иC High Product Quality and Safe for the family home

Technical Information:

• Pipe Centres: 150mm +/- 10mm
• Inlet Connection Size: G3/4" and G1/2"
• Minimum Bar Pressure: 0.05 Bar
• Maximum Bar Pressure: 0.5 Bar
• Shower Hose Length: 1500mm
• Shower Top to Bottom Adjustability: 732mm--1152mm

Main Head Flow Rates:

• 1.0 Bar - 3-5L/MIN
• 2.0 Bar - 6-8L/MIN
• 3.0 Bar - 9-11L/MIN

Handset Flow Rates:

• 1.0 Bar - 2-4L/MIN
• 2.0 Bar - 5-7L/MIN
• 3.0 Bar - 8-10L/MIN

Installation Video:

Anti-hot/Cool touch

A layer of anti-scalding material is added to the outer layer, and an apron is added to the valve core for double protection, safety and anti-scalding. In addition, new cold-touch technology is added. The internal flow channel of the main body is filled with cold water surrounding hot water, and hot water is surrounded in the center of the main body.

Can be quickly disassembled to remove dirt

When the water quality is poor and there is no water due to sediment and dirt, the inner core can be disassembled and cleaned with clean water,The operation is simple and convenient.

Prevent water leakage

Level 10 corrosion-resistant technology is not afraid of humid environments and is more resistant to corrosion and scratches. It has passed the 96-hour acid salt spray test. Various corrosive liquids containing acid and alkali substances will not damage the surface layer, and the main body has no risk of water leakage.

Environmental friendly

Made of environmentally friendly materials, simplified machining, main body wall thickness 1.2-1.5mm can be achieved, superimposed high-quality waterway design, zero lead output.

Polished Chrome Finish

Polished chrome finishes are very popular in a bathroom, bringing style and important practicality. Chrome is super easy to clean and will match perfectly with other chrome fittings and accessories.

Solid Brass Body

Has your shower been the same one since you moved in several years ago? It's probably about time you gave it an update, especially as your shower is used every day. This shower valve has been constructed from a good quality solid brass, which is designed to be long-lasting and finished to a high standard.

Maintains Constant Temperature In All Conditions

Standard showers can have hot temperature spikes when others in the house turn on taps or flush the toilet.Thermostatic control means that this shower will hold its temperature steady at all times. It dynamically adjusts the mix of hot and cold water offsetting the everyday changes in water pressure experienced in most family homes.

Dimensions:
