Airless paint spray system Scheppach ptsa600

Airless Painting System Scheppach PTSA600 – Ideal for Indoor and Outdoor Coating Applications

The Scheppach PTSA600 airless painting system is suitable for all types of painting work and ensures a uniform and precise application both indoors and outdoors. It allows the optimal application of thick paints, latex, enamels, dispersion wall paints and water-based waterproofing coatings. The 15-metre flexible hose, powerful 950-watt motor and direct suction system that draws paint straight from the bucket enable fast and flexible work even on large surfaces.

Key Features

– Airless spray painting system for uniform paint application on smooth or rough surfaces, indoors and outdoors
– Suitable for thick paints, latex, enamels, dispersion wall paints and water-based waterproofing coatings
– Wide working radius thanks to the 15 m spray hose
– Powerful 950 W electric motor
– Spray gun adjustable horizontally and vertically, with lock function for long and effortless work
– Fast work progress up to 600 m²/h
– Maximum operating pressure of 227 bar, continuously adjustable via pressure regulator
– Practical frame with integrated carrying handle for easy transport
– Direct paint suction from the bucket thanks to the filter attachment on the suction hose
– Maximum flow rate 2.0 L/min depending on paint or fluid
– Includes nozzle for thick materials (517) with spray width 250–310 mm

Technical Data

Power: 950 W
Voltage: 230 V
Flow rate: 2.0 L/min
Spray width: 250–310 mm
Maximum surface output: 600 m²/h
Maximum working pressure: 227 bar
Hose length: 15 m
Dimensions: 410 × 350 × 300 mm
Packaging dimensions: 435 × 390 × 315 mm
Net / gross weight: 10 / 11 kg
