Product information

Description

General description

The AKW TriForm Linear Drain Level Access Wet Room Former Tray is designed to provide a stylish and functional solution for your shower area. Featuring a long, linear drain positioned at one end, this tray not only enhances the aesthetic appeal of your wet room but also ensures efficient drainage.

Technical specifications

  • Dimensions: 1000mm x 1000mm
  • Thickness: 22mm
  • Gradient: 1:40
  • Core Material: Glass Reinforced Plastic (GRP)
  • Maximum Weight Load: 254 kg (40 stone)
  • Drain Position: End (Linear)
  • Waste Suitability: Gravity, Pumped
  • Floor Covering Suitability: Tiled Floors
  • Floor Suitability: Wooden Floors, Concrete Floors
  • Compatibility and accessories

  • Suitable for 1, 2, or 3 shower wastes
  • Flow rate: Up to 78 litres per minute with multiple wastes
  • Infill pieces included to cap off any unused waste holes
  • Installation

  • Self-supporting design eliminates the need for underboarding
  • Pre-formed fixing holes for simplified installation
  • Usage

  • Designed for use with tiled floors only
  • Not suitable for vinyl flooring
  • Other information

  • Standard linear drain cover option is reversible - available in stainless steel or tiled finish
  • Lifetime guarantee from the manufacturer
  • Features

    • Brand
      AKW
    • Width
      1000 mm
    • Length
      100 cm
    • Warranty
      2.08333 year(s)
    • Colour
      White
