AKW TriForm Linear Drain Level Access Wet Room Former Tray 900mm x 900mm

Product information

Description

General description

The AKW TriForm Linear Drain Level Access Wet Room Former Tray is designed to provide a stylish and functional solution for your shower area. Featuring a long, linear drain positioned at one end, this tray not only enhances the aesthetic appeal of your wet room but also ensures efficient drainage.

Technical specifications

Dimensions: 900mm x 900mm

Thickness: 22mm

Gradient: 1:40

Core Material: Glass Reinforced Plastic (GRP)

Maximum Weight Load: 254 kg (40 stone)

Drain Position: End (Linear)

Installation Type: Level Access

Waste Suitability: Gravity, Pumped

Floor Covering Suitability: Tiled Floors

Floor Suitability: Wooden Floors, Concrete Floors

Compatibility and accessories

Suitable for 1, 2, or 3 shower wastes

Infill pieces are supplied to cap off any unused waste holes

Standard linear drain cover option is reversible - either a stainless steel or tiled finish

Installation

Includes pre-formed fixing holes to simplify and speed up installation

Self-supporting design eliminates the need for underboarding

Usage

Designed for use with tiled floors only

Can accommodate up to 3 wastes with a flow rate of up to 78 litres per minute

Other information

Lifetime guarantee from the manufacturer

Wet room floor former only - waste(s) and linear drain cover not included

Features

Brand
AKW
Width
900 mm
Length
90 cm
NF certification
NF254
Warranty
2.08333 year(s)
