AKW Tuff Form8 Rectangular Wet Room Floor Former with Rotatable Drain Outlet 1135mm x 770mm

Product information

Description

General description

The innovative Tuff Form8 wet room former features an octagonal waste plate that can be rotated to 1 of 15 different positions, making it easier than ever to avoid obstructions such as joists when laying your new level access shower floor. This rectangular tray is designed to support a maximum weight of 60 stone (381 kg) and is suitable for both wooden and concrete floors.

Technical specifications

Tray Size: 1135mm x 770mm

Thickness: 22mm

Gradient: 15mm (1:16)

Core Material: Sheet Moulding Compound (SMC)

Drain Position: Central (Rotatable - 15 Positions)

Maximum Weight Load: 381 kg (60 stone)

Compatibility and accessories

Suitable for use with vinyl floor or tiled floor coverings

Extensive waste options available separately for vinyl floors or tiled floors

Installation

Includes pre-formed fixing holes to simplify and speed up installation

Self-supporting tray - no need for under-boarding

Suitable for installation on wooden floors or concrete floors

Can be trimmed without losing strength (up to 150mm from the waste plate)

Usage

Designed for level access wet room installations

Compatible with underfloor heating systems

Other information

Supplied with a lifetime guarantee from the manufacturer

Additional product images show a 1400mm x 820mm model

Features

Brand
AKW
Length
113.5 cm
Width
770 mm
Height
22 mm
Material
Composite
