General description
The ANNKE 8CH CCTV Kit is a comprehensive security solution featuring a DVR with 1TB HDD and 5MP HD cameras. It offers advanced features such as Smart IR night vision, remote monitoring via mobile devices, and intelligent motion detection to enhance your home or business security.Technical specifications
- Video Compression: H.264+/H.264/H.265/H.265 Pro+
- Video Input: 8CH Analog HD/Analog + 2CH IP Video (up to 12 channels in IP enhanced mode)
- Video Output: HDMI and VGA Up to 1080P
- Audio Input: 1-ch RCA, 8-ch via coaxial cable
- Audio Output: 1-ch RCA
- Supported Camera Types: HD TVI, AHD, CVI, CVBS, IP Video Input (up to 6MP)
- Max Playback Channel: 8-ch
- Total Bandwidth: 96Mbps
- Operating Power: DC12V, ≤ 12W (without HDD)
- Working Temperature: -14 °F – 131 °F / -10 °C – 55 °C
- Dimensions (W x H x D): 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weight (without hard disk): ≤ 1 kg (2.2 lb)
- Camera Image Sensor: 5MP CMOS
- Camera Video Resolution: 2560 (H) X 1944 (V)
- Camera Lens: 2.8 mm
- Camera Night Vision Distance: Up to 100 ft / 30 m
- Camera Weatherproof Rating: IP67
- Camera Dimensions: Φ4.32” X 3.53” / Φ109.8 X 89.75 mm
- Camera Weight: 0.53 lb / 242 g
Compatibility and accessories
- Includes 1TB HDD for storage
- Compatible with iPhone, iPad, and Android devices for remote monitoring
Installation
- Easy setup with included instructions
- Connect cameras to the DVR using coaxial cables
Usage
- Remote access to live video feeds via mobile app
- Receive real-time push notifications and email alerts for detected movements
- Utilize the visual alarm feature to deter intruders
