Bristan Prism BB DC SHWR PK Shower Mixer PRISM BB SHWR PK

Name: Bristan Prism BB DC SHWR PK Shower Mixer PRISM BB SHWR PK
Brand: BRISTAN
SKU: PRISM BB SHWR PK
Price: 454.51 GBP
Availability: InStock

~~£624.17~~

Sold by BuyaParcel and 1 other seller

Product information

Description

General description

All in one box - pack includes shower valve with integral two outlet diverter, slimline 200mm round drench head with shower arm, and shower kit with an adjustable riser rail plus a multi-function handset and wall outlet. The on-trend brushed brass finish makes a statement in your bathroom.

Technical specifications

Body material: Brass

Shower kit height: 730mm

Shower arm length: 370mm

Shower head width: 200mm

Shower head depth: 200mm

Minimum pressure: 0.2 Bar

Maximum pressure: 5.0 Bar

Connection centres: 150mm

Inlet connection size: 15mm

Fitting depth (including plasterboard and tiles): 50mm - 75mm

Flow rates through handset (mixed): 0.2 Bar - 2.7 l/min, 0.5 Bar - 5 l/min, 1.0 Bar - 7.3 l/min, 2.0 Bar - 7.8 l/min, 3.0 Bar - 8.9 l/min, 5.0 Bar - 9.8 l/min

Flow rates through fixed head (mixed): 0.2 Bar - 3.6 l/min, 0.5 Bar - 5.9 l/min, 1.0 Bar - 6.5 l/min, 2.0 Bar - 8.1 l/min, 3.0 Bar - 8.5 l/min, 5.0 Bar - 9.6 l/min

Flow rates through handset (without flow regulators): 0.2 Bar - 31 l/min, 0.5 Bar - 5.8 l/min, 1.0 Bar - 8.7 l/min, 2.0 Bar - 12.9 l/min, 3.0 Bar - 16 l/min, 5.0 Bar - 21 l/min

Flow rates through fixed head (without flow regulators): 0.2 Bar - 5.9 l/min, 0.5 Bar - 9.3 l/min, 1.0 Bar - 13.5 l/min, 2.0 Bar - 19.5 l/min, 3.0 Bar - 23.3 l/min, 5.0 Bar - 24.8 l/min

Installation

Slim design recessed shower valve fits into a cavity space as small as 35mm for hassle-free installation.

Cartridge can be accessed from the front for easy servicing.

Usage

Dual control allows for separate operation of flow and temperature, providing accurate control.

Multi-function rub clean handset and drench head for easy maintenance; limescale and debris build-up can be quickly removed by rubbing a finger or cloth over the nozzles.

Other information

Guarantee: 5 years including parts (1 year on labour and 3 years on Gold, Painted and other Special Finishes).

EAN Barcode: 5014868078434

Manufacturer Part Number: PRISM BB SHWR PK

Features

Brand
BRISTAN
Length
20 cm
Width
20 cm
Height
73 cm
Diameter
200 mm
