Concealed hinge template, 35mm hinge hole cutter with drill locator for wooden furniture cabinet hinges and mounting plates

Sold by AINSCO and 1 other seller

Product information

Description

General Description

The concealed hinge jig is an essential tool for precisely drilling cabinet hinges and mounting plates. Designed to fit various types of drills, it eliminates debris and ensures a clean cut thanks to its super-hard alloy. This jig is ideal for DIY enthusiasts and professionals, offering excellent visibility and optimal stability during use.

Technical Specifications

Cutting Diameter: 35 mm
Material: High-impact polycarbonate
Included Drill Bit Type: Forstner Bits
Included Accessories: Hex Key

Compatibility and Accessories

Suitable for: Pillar drill, pistol drill, bench drill, vertical drill, portable electric drill, stand-mounted motor drill, magnetic drill, and mobile band drill.

Installation

Determine the position of the hinge cup with the short plate facing upwards.
Drill the hole for the hinge cup.
Mark the center line on the other board with the short plate facing downwards.

bottom.

Drill the hinge seat positioning hole.
Install the hinges.
Operation
- Set the maximum hole locator distance to 0-30 mm.
- Keep your hands and body away from sharp edges and moving parts.
- Ensure the drill locator is securely attached before operation.
- For improved performance, regularly lubricate the tool with grease.

Features

Brand
SNQ
Material
Polystyrene (PS)
Pcs per pack
1
Colour
Blue
Chuck diameter
35 mm
Height
1 cm
Compatible drill
Pillar drill
Type of drill accessory
Jig
Chuck
Hexagonal
Drilling support type
Drilling jig
ManoMano Reference
ME92268390
MMID
272109192090
Product code
FD-07205
EAN
6190246993571

Advice from

Drill accessories buying guide
