Draper Expert Composite Body Reversible Air Drill with Soft Grip, 10mm Keyless Chuck, 3/8 Inch Capacity

Description

The Draper Expert 14258 Composite Reversible Keyless Air Drill is a high-quality workshop tool designed for precision and durability. It features a lightweight and rugged composite body that reduces operator fatigue and minimizes the cold sink effect. The drill offers lower noise and vibration levels for comfortable extended use. It is equipped with a reversing function, planetary gear system, variable speed trigger, and a keyless Jacobs chuck for easy bit changes. The rotating air inlet prevents air line tangling, ensuring smooth operation.

Specifications

• Chuck size: 10mm
• Free speed: 1800 rpm
• Operating air pressure: 90psi (6.2bar)
• Average air consumption: 4 cfm (114 L/min)
• Vibration level: 2.5 m/s²
• Minimum hose size: 3/8" (10mm)
• Air inlet: 1/4" BSP
• Weight: 1.1 kg

Compatibility and Accessories

• Compatible with standard 10mm drill bits
• Uses a keyless Jacobs chuck for quick bit changes

Installation

• Connect the air inlet to a suitable compressed air source with a minimum hose size of 3/8" (10mm)
• Ensure the air pressure is set to 90psi (6.2bar)
• Insert the desired drill bit into the keyless chuck and tighten securely

Usage

• Use the variable speed trigger to control drilling speed
• Engage the reversing function for forward or reverse operation
• Operate the drill at an air pressure of 90psi for optimal performance
