General description
The Filter box G4 is designed for efficient air filtration in ventilation systems. Made from durable galvanised steel, it features a removable cover for easy maintenance and is equipped with a synthetic glass fibre filter (G4 / 89% filter grade) that can be washed up to 8 times. This filter box effectively prevents dirt and dust from infiltrating the system, ensuring cleaner air circulation.Technical specifications
- Material: Galvanised steel sheet
- Filter grade: G4 / 89% filter grade
- Max. temperature of transported air: +60°C
- Sizes available: NW 100 to NW 315
- Weight: Ranges from 2.1 kg to 6.1 kg depending on size
- Deposit efficiency: Approximately 90%
- Absorbed dust capacity: Approximately 135g/m²
Compatibility and accessories
Compatible with various duct sizes, the Filter box G4 is available in the following nominal widths: AF 100, AF 125, AF 150, AF 160, AF 200, AF 250, and AF 315. Optional accessories are also available in the shop.Installation
For optimal performance, install the filter box in ventilation systems in front of the fan or sound absorber, ensuring it is positioned in the direction of airflow. Sufficient clearance space must be maintained according to dimension D for filter replacement.Usage
The filter should be cleaned when the initial pressure has doubled and replaced when it starts to decompose due to frequent washing.Other information
