G1/2-G1/2 Thread Water Pump Flow Sensor Electronic Pressure Automatic Control Switch 220V

1、Stable performance; induction chamber, magnetic control chamber and electronic components are designed separately in order to avoid switch failure caused by iron matter in pipeline is magnetic adsorbed.

2、High temperature resistant materials allows the product to be used for both hot(up to 70℃) and cold water.

3、Low water pressure startup; reset spring is made of high quality stainless steel; it can start up pump when water pressure is >0.03KG.

4、The electronic components as control device will not cause spark during work which is quite safe.

5、This product is widely used for low pressure area family, especially important for low water pressure ignition start-up of water heater, automatic water cycle of solar water heater.

Turn on the water

equipment and water will flow in pipeline. Water impulse induction door

to rotates towards the direction of water, and magnetic control device

rotates together, which will trigger the sensing elements when it

reaches a certain position, to switch on the household pipeline boost

pump. When water flow is turned off, induction door drives magnetic

control device to a certain position under the action of the reset

spring, to switch off pump.

Features:

Stable

performance; induction chamber, magnetic control chamber and electronic

components are designed separately in order to avoid switch failure

caused by iron matter in pipeline is magnetic adsorbed.

High temperature resistant materials allows the product to be used for both hot(up to 70℃) and cold water.

Low

water pressure startup; reset spring is made of high quality stainless

steel; it can start up pump when water pressure is >0.03KG.

The electronic components as control device will not cause spark during work which is quite safe.

This

product is widely used for low pressure area family, especially

important for low water pressure ignition start-up of water heater,

automatic water cycle of solar water heater.

Specification:

Model: HT-200

Rated Voltage: 220V

Overload Current: 2A

Connection Thread: G1/2-G1/2

Suitable Liquid: Water or other liquid of similar physical and chemical property

Liquid Pressure: <0.6Mpa

Liquid Temperature: <70℃

Weight: 183g / 6.5oz (approx.)

Package list:

1 * Flow Switch

2 * Gaskets
