Green Self-Leveling Laser Level, 4 x 360° 16 Laser Lines for Construction Sites, 2 x Rechargeable Batteries, Rotating Laser Level with Rotating Mount, Remote Control

~~£127.66~~

Of which environmental contribution £0.10 including VAT.

Sold by Sinocor GmbH

Product information

Description

General Description

The green self-leveling laser level is a versatile tool that emits 16 horizontal, vertical, and diagonal laser lines, enabling precise automatic leveling. It is designed for a variety of applications such as tile laying, partition wall installation, and finish carpentry. Thanks to its self-test calibration function, it guarantees easy and efficient use, even on surfaces inclined up to 3°.

Technical Specifications

Main Material: Plastic + Metal
Battery: 2 rechargeable lithium batteries, 3.7V, 2400mAh (included)
Line Type: 4 * 360°, 16 lines
Wavelength: 532nm (green)
Self-Leveling Angle: ± 3°
Machine Dimensions (with battery): 133 * 105 * 130 mm
Base Size: 97 * 87 * 68 mm
Wall Mount Size: 75 * 83 * 161 mm
Size of the Ironing board: 100 * 60 * 12 mm
Platform size: 115 * 91 * 31 mm
1/4 inch to 5/8 inch adapter: 21 * 21 * 25 mm
Clip holder size: 62 * 24 * 27 mm
Package size: 278 * 240 * 135 mm
Package weight: 1891 g

Compatibility and Accessories

T-shaped bracket with 7 mm wall mounting distance
1/4 inch to 5/8 inch threaded base (included)
1/4 inch to 5/8 inch adapter (included)
Durable plastic carrying case shocks

Installation

Can be mounted on a tripod (not included) via a 1/4-inch thread
Use of the compass bubble to check horizontality

Use

Emitters visible laser lines for staking and calibration
Tilt mode to create lines at an arbitrary angle
Adjustable number of laser lines and their brightness
Continuous and pulsed laser functionality

Other information

Do not look directly at the laser light
Do not disassemble the instrument
The laser output generator is located at the output hole
Complies with laser radiation safety standards

Features

Brand
TEHTUY
Length
13.3 cm
Warranty
1 year(s)
Number of laser lines
16
Beam colour
Green
Self-levelling (feature)
Yes
Battery or cell included
Yes
Laser class
2
Remote operation
Yes
Light colour
Green
Availability of spare parts
1 year(s)
Self-stabilizing beam
Yes
Laser shape
Cross
Height
130 mm
Material
Metal
Parallel leveling (360°)
Yes
Weight
100 g
Plumb mark
Yes
Type of battery
Refillable
ManoMano Reference
ME98923911
MMID
350677810875
Product code
ZJL-mano-05218
EAN
6282768125704
