General description
The Hikoki NR1890DCAJPZ 18V Brushless 2nd Generation 90mm Clipped Head Framing Nailer is designed for high-powered performance, capable of driving up to 90mm nails at a speed of 2.7 nails per second. Its compact and lightweight design ensures ease of use and optimal control, while the air-spring drive system provides a smooth, pneumatic-like feel. The aggressive nose design prevents slippage, enhancing accuracy for skew nailing. A bright LED light improves visibility in dark spaces, and the tool-free depth adjustment feature adds to its convenience.Technical specifications
- Part Number: NR1890DCAJPZ
- Barcode: 4966376415943
- Voltage: 18V
- Type of Motor: Brushless
- Nail Length: 50 to 90 mm
- Applicable Nails Shank Diameter: 2.9 to 3.3 mm
- Driving Speed: Up to 2.7 nails/sec
- Driving Mode: Full sequential / Contact
- Nail Capacity: 50 nails
- LED Light: Yes
- Depth Adjustment: Tool-free
- Nail Collation Angle: 30° to 34°
- Dimensions (H x L x W): 359 x 315 x 133 mm
- Weight (With BSL1850MA battery): 4.4 kg
Compatibility and accessories
- 2 x 5.0Ah Li-ion batteries
- 1 x UC18YSL3 Charger
- 1 x Rubber Nose
- 1 x Stackable System Case
Installation
No air hose or compressor is required for operation, making installation straightforward. The tool-free depth adjustment allows for quick setup.
Usage
The Hikoki NR1890DCAJPZ is ideal for driving nails into lumber with ease. It features a selective activation button for choosing between sequential or bump fire mode, enhancing versatility for various applications.
Other information
The dry fire lockout system prevents the nailer from operating when fasteners are low, ensuring safety. Additionally, it includes a lock switch and a 30-minute automatic shutdown feature for increased safety and longer battery life.
