Input Wide Voltage Output ±7.5V Precision Voltage Reference Source Board ( Output ±7.5VDC)
You may also like
Compare with similar items
Product information
Description
1、100% brand new and high quality
2、TL431 Positive & Negative Dual Output ±1% Precision voltage reference source Module
3、Applications:Operational Amplifier : LM324 LM358 AD101 AD201 Etc.ADC : ADC0809 MAX160 AD7705 Etc.DAC :DAC0832 PCF8591 TL5615 MPC4822 TL5610.Replace AD584 LM399 LM4040 MC1403 LM326 AD637AD584;Audio equipment;RS232 RS485 RS422 Bus;LCD voltage reference;In
4、The terminal has good contact performance, ensuring stable working
5、Adopted of high quality electronic components, and precision process,itensures for the durability
Features:
TL431 Positive Negative Dual Output ±1% Precision voltage reference source Module
Applications:Operational Amplifier : LM324 LM358 AD101 AD201 Etc.ADC : ADC0809 MAX160 AD7705 Etc.DAC :DAC0832 PCF8591 TL5615 MPC4822 TL5610.Replace AD584 LM399 LM4040 MC1403 LM326 AD637AD584;Audio equipment;RS232 RS485 RS422 Bus;LCD voltage reference;Instrumentation equipment; Wifi/Router/Ethernet devices
The terminal has good contact performance, ensuring stable working
Adopted of high quality electronic components, and precision process,itensures for the durability
2.54mm pin pitch,for MCU Development Board Breadboard friendly.
Specification:
Output voltage:±2.5V,±3.3V, ± 5V, ±7.5V , ±10V, ±12V (Optional)
±2.5V :
Input Voltage±3.5-10.1V,Output Voltage±2.5V
Input Current 2.5-16MA,MAX Output Current 0.6-14MA
±3.3V :
Input Voltage±4.3-10.9V,Output Voltage±3.3V
Input Current 2.5-15MA,MAX Output Current 0.6-13MA
± 5V :
Input Voltage±6-12.6V,Output Voltage±5V
Input Current 2.1-16MA,MAX Output Current 0.1-13MA
±7.5V :
Input Voltage±8.5-15.1V,Output Voltage±7.5V
Input Current 3-16MA,MAX Output Current 1-14MA
±10V :
Input Voltage±11-17.6V,Output Voltage±10V
Input Current 3-15MA,MAX Output Current 1-13MA
±12V :
Input Voltage±13-19.6V,Output Voltage±12V
Input Current 3-14MA,MAX Output Current 1-12MA
Accuracy :±1%
Operating temperature range : -40~+125 Degrees Celsius
Storage temperature range : -65~+150 Degrees Celsius
Size : 19 * 13 * 2.8mm / 0.7 * 0.5 * 0.1in
Weight: 2.5 g / 0.1 oz(approx.)
Package list:
1 x Voltage Reference source Board
Features
- BrandSTUNACY
- Length3 cm
- Width3 cm
- Height1 cm
- ManoMano ReferenceME220938494
