Insulating Rubber Lined U-bolt and Backing pad 29 mm ID (suit 20 mm NB pipe)-Galvanised

Sold by Graphskill

You may also like

Heavy-Duty Cable Ties White 9.0 x 900mmFAITHFULL
3 options

Heavy-Duty Cable Ties White 9.0 x 900mm

Free shipping
Sealey Cable Tie 200 x 4.4mm Green Pack of 100 CT20048P100GSEALEY
2 options
#1 in sales

Sealey Cable Tie 200 x 4.4mm Green Pack of 100 CT20048P100G

3
Free shipping

Compare with similar items

Product information

Description

General description

Insulating Rubber Lined U-bolt and Backing pad with a 29 mm inner diameter, suitable for 20 mm nominal bore pipes. This product is designed to prevent galvanic corrosion caused by the contact of dissimilar metals in the presence of an electrolyte, as well as to protect against wear and crushing of composite, thin wall, or non-ferrous pipework.

Technical specifications

  • Pad Material: Neoprene Rubber
  • Elastomer: Neoprene
  • Colour: Black
  • Quality: Commercial
  • Grade: C20
  • Hardness: 65 shore A +/-5
  • Specific Gravity: 1.4 G/Cm3
  • Tensile Strength: 5 MPA (minimum)
  • Elongation: 300%
  • Tear Strength: 20 Kg/CM
  • Compression Set: 35%
  • Operating Temperature: -20 to +110 °C
  • Sleeve: 300 psi Black Air Hose (ISO2398)
  • Tube Material: Black NBR/SBR synthetic rubber
  • Reinforcement: Synthetic textile
  • Cover Material: Black, weather and ozone resistant SBR/EDPM
  • Temperature Range: -20 to +90 °C
  • U-Bolt: Galvanised
  • Includes: 2 nuts on each leg
  • Dimensions: NB = 20 mm, Pipe O/D = 26.9 mm, A = 29 mm, B = 43 mm, C = 70 mm, D = 6 mm, E = 60 mm, F = 65 mm, G = 13.5 mm, D*A (backing pad) = 25*10 mm
  • Tolerance on dimensions: +/- 1 mm
  • Note: Bar diameter is slightly less than the thread diameter due to roll threading
  • Usage

    This product is ideal for general workshop use and with compressors, providing effective insulation and protection for piping systems.

    Other information

    Also available in zinc plated or galvanised upon request.

    Features

    • Brand
      GRAPHSKILL
    • NF certification
      NF110
    • Certification body
      ISO
    • Colour
      Black
    • Product finish
      Galvanised
