Lindström Electronic Diagonal Cutter, SFW Model, Total Length: 108 mm

Description

• This precision-cutting plier features induction-hardened blades with a hardness of 63-65 HRC, ensuring durability and sharpness. It has a white conductive plastic handle with an opening spring, making it suitable for ESD applications. The specially designed joint with extended contact surfaces minimizes unwanted movement, providing highly accurate axial alignment of the jaws. Ideal for cutting copper wires up to 1.25 mm in diameter.

Technical specifications

• Overall length: 108 mm
• Head length: 8 mm
• Blade width: 10.5 mm
• Cutting length: 15 mm
• Cutting capacity for copper wire: up to 1.25 mm diameter
• Material: Special ball bearing steel, drop-forged
• Manufacturing process: Induction-hardened blades (63-65 HRC)
• Handle: Conductive plastic
• Includes opening spring: Yes
• Electrical insulation: ESD-compatible

Compatibility and accessories

• Suitable for professional and hobbyist use in electronics and home improvement projects
• Compatible with standard copper wires up to 1.25 mm diameter

Installation

• No installation required; ready to use out of the box

Usage

• Use for precise cutting of copper wires and small electrical components
• Ensure the wire is properly positioned between the blades before cutting

Other information

• Note: Decorations are not included
