Liquid Level Controller Automatic water liquid Control Module Water Level Detection Sensor

1、Three color LED indicater

2、allowing the water level is maintained at a low level and high level between

3、easy to switch the function

4、 the sensor is not prone to rust and can prevent the wire from floating

5、You can replace the sensor directly with a wire

Description:

Three color LED indicate low (red), medium (yellow),

high (green) water, low water pumping or high-water pumping

can be switched on and off when you press the function switch bounce

(ie not pressed) when low water relay (external pumps work),

start adding water, the water level rises to a high level relay off (pump stopped working)

until the water level drops below the low water level again relay again, the above process cycle.

This feature is used in automatic water equipment,

allowing the water level is maintained at a low level and high level between.

When the function switch when pressed, when the high-water relay (external solenoid valve),

begins to drain, the water level drops below the low water relay off (solenoid valves stop working)

until the water level rises again to the high-water relay pull again, the above process cycle.

This feature is used in automatic drainage device,allowing the water level is maintained between low water and high water level.

Specifications:

work voltage:5V

Relay contact capacity:10A / 250V

controller size:42*69mm

sensor size:83*21mm

Package includes:

1 x Liquid Level Controller Module Water Level Detection Sensor

Note:

1.Due

to different producing batches, product details might be a little

different. If you minding the difference, please buy it carefully.

2.Please allow 1-3mm differs due to manual measurement.

3.Item

color displayed in photos may be showing slightly different on your

computer monitor since monitors are not calibrated same
