Marley fan fresh air heat recovery unit MEnV180

Name: Marley fan fresh air heat recovery unit MEnV180
Brand: MARLEY
SKU: 320670
Price: 539.99 GBP
Availability: InStock
Rating: 5 (1 reviews)

#1 in sales

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by creoven

Product information

Description

General description

The Marley fan fresh air heat recovery unit MEnV180 is designed to provide efficient ventilation while recovering heat, ensuring a comfortable indoor environment. It features adjustable ventilation settings and is easy to install without the need for complex pipe laying.

Technical specifications

Operating voltage: 220-240 Volt ~ 50/60 Hertz

Motor voltage: 24 V DC

Airflow: 16 / 25 / 37 m³/h

Power consumption: 3 / 4.5 / 7 Watt

Efficiency factor: max. 85%

Sound pressure (3 m): 22 / 29 / 35 dB(A)

Sound insulation from the outside: 39 dB

Outer wall thickness: 280 - 500 mm

Size of cover: 240 x 240 mm

Diameter of drill hole: 180 mm

Weight: 4.78 kg

Protection class: II (double protective insulation)

Protection code: IPX2 (inside), IPX4 (outside)

Compatibility and accessories

Ready-for-use system including:

Design cover with controller functions

Wall duct with insulating tube (adjustable in length)

G3 filter unit

Ceramic heat exchanger

Outer unit with fan and cover

Remote control

Assembly instructions with drill template and screws

Features

Brand
MARLEY
With filtered supply air
Yes
VMC feature
Energy saving
Energy efficiency rating
B
Heating savings
Yes
Filter ISO Efficiency
G3
Included elements (vmc)
VMC Kit
Material
Metal
Weight
5180 g
Noise level
35 dB
Type of VMC box
Dual-flow
VMC type
MVHR system kit
ManoMano Reference
ME4741481
MMID
547602373293
Product code
320670
EAN
4002644320670

Customer reviews

5,0

/ 1 Reviews

Reviews verified by ManoMano

MManoMano Customer

Published on 27/12/2018, Italy

Very useful, the delivery was on time with the expected date, congratulations manomano
