Mixed-Flow Inline Fan Boost I 200 T

Product information

Description

General description

The Mixed-Flow Inline Fan Boost I 200 T is designed for efficient ventilation in both residential and commercial properties. It is particularly effective for air extraction in damp rooms, providing high pressure while maintaining a low noise level.

Technical specifications

Voltage: 220-240 V ~ 50 Hz

Housing colour: silver

Housing material: galvanised steel

Acoustic material layer: 30 mm for sound and heat insulation

Nominal size: 200 mm

Bearings: ball bearing

Speed levels: 3

Wattage: 82 / 104 / 113 W

Current consumption: 0.37 / 0.46 / 0.51 A

Revolutions per minute: 2229 / 2634 / 2823

Airflow rate: 692 / 906 / 1110 m³/h

Airflow rate: 192 / 252 / 308 l/s

Sound pressure Lp-3m: 37 / 42 / 44 dB(A)

Diameter: 281 mm

Diameter with terminal box: 339 mm

Length: 739 mm

Diameter duct connection: 199 mm

Weight: 8.2 kg

Max. temperature of transported air: -25 to +55°C

IP rating: IPX4

IP rating motor: IP20

Adjustable shut-off timer: 2-30 min

Installation

The fan can be mounted in any position, providing flexibility for installation in various settings.

Usage

This inline fan is ideal for ventilation systems that require high pressure and low noise levels, making it suitable for air extraction in damp rooms.

Features

Brand
VENTS
Colour
Grey
Shape
Cylindrical
IP rating
IPX4
Material
Steel
