Product information
Description
Features and Benefits:
- Shower valve supplies water to 2 outlets
- Manufactured from high quality brass & ABS
- Minimalist sleek design
- Can be fitted vertically or horizontally
- Accurate flow control
- Made in Britain
- Thermostatic control to +/- 2 degrees even if the water pressure fluctuates
- Full thermal protection to prevent scalding in the event of hot or cold water shut off
- In the event of hot or cold water failure the valve will shut down as per the relevant standard
- The unique cartridge is highly resistant to calcium build up - even in hard water areas
- Our valves are suitable for use with all systems: gravity fed pumped unvented high pressure or fully modulated combi-boilers
- Excellent flow rates - even at low pressures
- The cartridge is fully reversible meaning if hot and cold supplies are the wrong way round it doesn't need re-plumbing
- Simply remove the cartridge turn 180 degree and replace
- WRAS approved product
- TMV2 Approved
- During installation extra care must be taken to avoid damaging the fittings
- Guarantee : 5 Year (12 months on serviceable moving parts from the date of purchase), please see manufacturer guarantee policy for more information
| Shower Type | Thermostatic |
|---|---|
| Shower Valve Controls | 3 |
| Shower Valve Position | Concealed |
| Valve Shape | Oval |
| Handle Type | Knob/Lever |
| Shower Valve Outlets | 2 |
| Minimum Pressure | 0.1 Bar |
| Shower Valve Height | 280mm |
| Shower Valve Width | 80mm |
| Shower Valve Depth | 72-85mm |
| Inlet Connection Size | 1/2 BSP |
| Outlet Connection Size | 1/2 BSP |
| Material | Brass/ABS |
| Colour | Chrome |
| Brand | Nuie |
| Collection | Arvan |
| Style | Modern |
| Market | Domestic |
| Weight | 3.45 Kg |
| WRAS Approved | Yes |
| WRAS Approval Number | 250602040 |
| TMV2 Approved | Yes |
| TMV2 Approval Number | 2603035 |
| EAN Barcode | 5056211898696 |
| Manufacturer Part Number(s) | ARVTR02 |
| Flow Rate @ 0.1 Bar | 5.5 l/min |
| Flow Rate @ 0.5 Bar | 14 l/min |
| Flow Rate @ 1.0 Bar | 20 l/min |
| Flow Rate @ 2.0 Bar | 29 l/min |
| Flow Rate @ 3.0 Bar | 44 l/min |
Features
- Length13.6 cm
- Width8 cm
- Height28 cm
- Weight3.4 kg
- MaterialBrass
