Orbit Viva Fully Back to Wall Close Coupled Rimless Pan Push Button Cistern - Excluding Seat

Name: Orbit Viva Fully Back to Wall Close Coupled Rimless Pan Push Button Cistern - Excluding Seat
Brand: ORBIT
SKU: VIVA001+VIVA003
Price: 257.95 GBP
Availability: InStock

Sold by Heat & Plumb

Product information

Description

General description

Supplied complete with a toilet pan and cistern, this Orbit Viva Fully Back to Wall Close Coupled Rimless Pan features a modern design that is easy to install and clean. Manufactured from high-quality vitreous china, it is finished in white to match existing sanitaryware. The rimless design enhances hygiene and ease of maintenance.

Technical specifications

Toilet Type: Close Coupled

Flush Type: Push Button

Total Height: 820 mm

Cistern Width: 370 mm

Toilet Projection: 607 mm

Toilet Pan Height: 425 mm

Toilet Pan Outlet: Horizontal

Connection Size: 102 mm

Toilet Seat Hole Centres: 155 mm

Cistern Full Flush: 6 Litre

Cistern Half Flush: 4 Litre

Material: Vitreous China

Colour: White

Weight: 44.8 Kg

Brand: Orbit

Collection: Viva

Style: Modern

EAN Barcode: 5060713720560, 5060713720584

Manufacturer Part Number(s): VIVA001, VIVA003

Other information

Toilet seat sold separately (please select from the options above). Guarantee: Lifetime (does not cover any product that has been modified, altered, transformed, or relocated in any way).

Features

Brand
ORBIT
Length
60.7 cm
Width
37 cm
Weight
44.8 kg
Volume
6 l
