Oval Mirror Radiator & Valves - 1800mm x 500mm - Anthracite Grey

Product information

Description

General description

Infuse warmth into your home with our cutting-edge oval panel vertical radiator in anthracite grey, featuring a sleek central mirror and a thermostatic chrome valve set. This product is a perfect blend of timeless elegance and modern efficiency, crafted with precision from premium 1.5mm carbon steel for durability and impressive aesthetics. Standing tall at 1800mm and spanning 500mm in width, it fits seamlessly into various spaces, enhancing the ambiance of any room.

Technical specifications

Colour: Anthracite Grey

Weight: 37.75kg

Material: 1.5mm Carbon Steel

Finish: Triple Layered Powder Coating

Height: 1800mm / 180cm / 70.9”

Width: 500mm / 50cm / 19.7”

Radiator Depth: 78mm / 7.8cm / 3.1”

Depth With Bracket: 103mm / 10.3cm / 4.1”

Individual Tube Size: 50mm / 5cm / 2”

Gap Between Tubes: 9mm / 0.9cm / 0.4”

Number Of Columns: 6

BTU Rating @ 50: 3944

BTU Rating @ 60: 5009

Mirror Dimensions: 1800mm x 145mm

Mirror Thickness: 5mm

Inlets/Outlets Size: Standard 0.5" BSP Bore

Testing: BS EN 442 & ISO9001:2015 Standards

CE Certificate: CE & UKCA

Compatibility and accessories

Compatible with all UK & EU heating systems

Includes: 1 x Oval Panel Mirror Radiator, 4 x Secure Brackets, 1 x Practical Fixing Kit, 1 x Flexible Cleaning Brush, 1 x Thermostatic Valve Set

Installation

All fixtures and fittings included for hassle-free installation

Usage

Thermostatic valve with rotary knob control for precise temperature management

Temperature range: 6 to 28 degrees

Lockshield functionality to regulate water flow for maximum efficiency

Other information

Protected by a sturdy steel plate on the back for extra support

Backed by a 15-year quality guarantee

Weight of valve: 0.9kg

Valve material: Brass with polished chrome finish

Maximum bar pressure: 12

Maximum flow temperature: 100 degrees

Nominal flow rate: 2.8L/m

Guarantee length for valve: 10 years

Features

Brand
MONSTER-SHOP
Colour
Anthracite
Material
Steel
Origin
Made in China
With fixings supplied
Yes
Radiator feature
Programmable
Energy efficiency rating
A
Max. energy efficiency rating
A
Min. energy efficiency rating
G
Height
1800 mm
Width
50 cm
Heating element
Steel
Radiator type
Hot water
ManoMano Reference
ME88063645
MMID
172525886402
Product code
10726
EAN
5055986194125
