General description
High-definition surveillance system featuring 4 outdoor IP cameras with 5MP resolution. The system supports advanced H.265+ video compression, ensuring efficient storage and high-quality recordings. It includes a robust metal housing for durability and is designed for both indoor and outdoor use, with an IP66 weatherproof rating.Technical specifications
- Video Resolution: 5MP (2880x1616)
- Image Sensor: 1/2.8" Progressive Scan CMOS
- Video Compression: H.265+
- Audio Compression: G.711A
- Lens: 3.6mm
- Angle of View: 70°
- Number of Infra-Red LEDs: 36
- Night Vision Distance: Up to 100ft/30m
- Wide Dynamic Range: Digital WDR
- IR Cut Filter: Yes
- Ethernet: RJ45x1 (10M/100M)
- Operating Power: DC12V; PoE (802.3af)
- Operating Temperature: -4 °F – 140 °F / -20 °C – 60 °C
- Dimensions (Camera): 6.7” x 2.6” x 2.6” / 170 x 65 x 65mm
- Weight (Camera): 0.772lbs / 350g
- NVR Max Recording Resolution: Up to 8M (3860x2160)
- NVR Dimensions: 10.2” x 9.6” x 1.9” / 260x245x47mm
- NVR Weight (without HDD): 1.68lbs / 760g
- HDD Capacity: Up to 12TB
- POE Ports: 8 Ports (IEEE802.3at/af)
- Power Consumption: 10W (without HDD)
- Working Temperature (NVR): 32 °F – 131 °F / 0 °C – 55 °C
Compatibility and accessories
- Compatible with IP cameras supporting H.265+/H.265/H.264+/H.264 formats
- Includes: 1 NVR, 1 Power Supply, 1 NVR User Manual, 4 Cameras, 1 Camera User Guide
Installation
The NVR is plug-and-play, making it easy to set up and connect to the IP cameras via Ethernet cables. This ensures a straightforward installation process for your home security system.Usage
Receive instant email notifications with snapshots and app alerts when motion is detected in your customized zones, allowing you to monitor your home effectively even when you are away.Other information
