Single-phase electric sub-meter, single tariff, LCD display, white, AC220V 5(20)A

~~£37.57~~

Of which environmental contribution £0.10 including VAT.

Sold by A10 ROOFING (LONDON) LIMITED

Product information

Description

General description

The Single-phase electric sub-meter is designed for accurate measurement of electrical energy consumption. It features a backlit LCD digital display that cycles through power consumption, voltage, current, and power readings, making it user-friendly and efficient.

Technical specifications

Model: DDM15SD

Material: ABS

Accuracy: First-class

Reference voltage: 220V/50Hz

Current: 5-20A

Power: 17000W

Display: Backlit digital LCD screen

Pulse output: 1000imp/kWh

Installation: 35mm DIN rail

Bar width: 17.5mm

Wiring method: Top-out and bottom-in/top-in and bottom-out

Ambient temperature: -20°C to +50°C

Installation

The sub-meter is designed for easy installation on a 35mm DIN rail, with a shaft width of 17.5mm. It supports multiple wiring methods for flexibility during setup.

Usage

This electric sub-meter is ideal for monitoring electricity consumption in residential or commercial settings, providing accurate readings for effective energy management.

Other information

Packaging includes: Electricity meter*1 in carton packaging

Features

Brand
CYSLMUK
Amperage
5 A
Accuracy class
Class 1.0
Control function
Yes
Frequency
50 Hertz
