TONYSA AC 220V Timer Relay Module, 1 to 99 Seconds/1 to 99 Minutes Delay Timer Relay Activation Circuit

English: Function: The trigger starts the countdown. The relay is activated and deactivated immediately after the countdown expires. The medium trigger stops immediately. Display mode: 2-digit red digital display. During the countdown, the remaining time is displayed; otherwise, the set time is displayed. Time setting: The time is set via a 500kΩ potentiometer and displayed dynamically on the digital display during the setting process. Output mode: Passive output mode, potential-free contact, dead-end, switching value, equivalent to a switch. 220V Time Delay Relay Module, Potential-Free Contact Time Relay, Timer Relay Module, Timer Switch Module, Countdown Timer, LED Time Relay Module, 12V Time Delay Relay. Specifications: Item type: Delay Relay Module. Voltage: 220V AC (160V-250V operation possible). Power consumption: 1.0W. Time range: 1-99 seconds or 1-99 minutes. English: Display mode: 2-digit red digital display (the remaining time is displayed during the countdown; otherwise, the set time is displayed). Time setting: potentiometer (500K), dynamic display on the digital display during setting. Accuracy: 1 (seconds or minutes, depending on the jumper). Error: 2%. Trigger mode: short circuit for more than 0.02 seconds. Output contact: a set of normally open and normally closed contacts. Output current: 10A (voltage range 0-250VAC or 0-30VDC). Output mode: passive (potential-free contact, no output, switching value, equivalent to a switch). Interface description: L220V input: phase. N220V input: line. NO: normally closed terminal of the relay. COM: common terminal of the relay. NC: normally open terminal of the relay. Note: "ON" in the function description means that the relay is connected to the common terminal and is normally open.
Scope of delivery:
1x delay relay module
