Nuie Edwardian Chrome Concealed Manual Shower Valve - A3201

Name: Nuie Edwardian Chrome Concealed Manual Shower Valve - A3201
Brand: NUIE
SKU: a3201
Price: 88.95 GBP
Availability: InStock

Sold by Heat & Plumb and 1 other seller

Often purchased together

Product information

Description

General description

Not everyone is a fan of modern styles; some prefer traditional aesthetics. The Nuie Nostalgic Manual Concealed Shower Valve embodies this classic design, making it an ideal addition to any family bathroom. Crafted from solid brass, this valve promises durability and strength, ensuring it stands the test of time. While it boasts a traditional appearance, it incorporates modern functionality and design.

Technical specifications

Valve Type: Manual Shower Valve

Position: Concealed

Height: 35mm

Width: 150mm

Weight: 1.76 Kg

Material: Brass

Finish: Chrome

Minimum Pressure: 0.2 Bar

Maximum Pressure: 3.0 Bar

Inlet Connection: 15mm (1/2 BSP)

Connection Centres: 150mm

Flow Rate - 0.5 Bar: 10 l/min

Flow Rate - 1.0 Bar: 14 l/min

Flow Rate - 2.0 Bar: 20 l/min

Flow Rate - 3.0 Bar: 26 l/min

Guarantee: 5 Year (12 months on serviceable moving parts)

Compatibility and accessories

Suitable for combi-boilers and gravity-fed systems

Compatible with low-pressure systems

Shower Riser Kit sold separately

Installation

Can be fitted vertically or horizontally

Extra care must be taken during installation to avoid damaging the fittings

Usage

Manually controlled

Accurate flow control

Supplied with a concealing plate for exposed or concealed options

Other information

Patented cartridge resistant to calcium build-up

Built-in anti-scald device

Manufactured in Britain

Features

Brand
NUIE
Colour
Grey
Warranty
5 year(s)
Material
Brass
Origin
Made in the United Kingdom
Adapted for PRM
No
With waste included
No
With anti-limescale function
No
Max. flow rate
26 l/min
Intended use of the tap
Shower
Hand shower included
No
Pull-out spray
No
Water saving
No
Pipe thread size
1/2" (15x21)
Output thread
1/2" (15x21)
Shape
Rounded
Height
3.5 cm
Mixer shower includes
Fixing
Flow limiter
No
Temperature limiter
No
Tap activation mechanism
Mechanical
Thermostatic mixer
No
Number of outlets
1
Weight
1.8 kg
Operating pressure
3 bar
Max pressure
3 bar
Pressure
3 bar
Pcs per pack
1
Concealed tap
Yes
Wall-mounted tap
No
38°C Safety
No
Tap head only
No
Cool body thermostatic
No
Type of installation method
With stand
Tap type
Single-lever mixer
Installation type
Wall mounted
ManoMano Reference
ME69637
MMID
568353027734
Product code
a3201
EAN
5055146110248
