Professional Ceiling Fan Nordik Heavy Duty Inox 160

Width: 152 cm

Power: 85 W

Colour: Black

Sold by creoven

Product information

Description

General description

The Professional Ceiling Fan Nordik Heavy Duty Inox 160 is designed for industrial and commercial environments, providing efficient airflow and durability. Its robust construction makes it suitable for areas with high levels of moisture, dust, dirt, and high temperatures.

Technical specifications

Voltage: 220-240 V ~ 50 Hz

Diameter: 152 cm / 60"

Housing colour: stainless steel (aluminium die casting, stainless steel 304)

Blade colour: stainless steel (stainless steel 304)

Motor wattage: 85 W

Revolutions per minute: 210

Max. airflow rate: 321.6 m³/min / 11357 cfm

Max. sound pressure level Lp-3m: 38.1 dB(A)

Max. sound power level: 55.6 dB(A)

Overall drop: 49.5 cm / 19.5"

Diameter canopy: 14.5 cm / 6"

Diameter motor housing: 22.5 cm / 9"

Weight: 8.6 kg / 18.9 lbs

Compatibility and accessories

Not suitable for sloping ceilings

Control unit not included

Installation

Forward and reverse function (summer/winter mode) via additional switch (to be provided on-site)

Usage

Application: industrial and commercial production, agriculture

Other information

IP code: IP55 protection against water jets

Insulation class: I

Ambient temperature: -10°C to +50°C

Certified for use in professional environments according to machinery directive 2006/42/EC part 1

Features

Brand
VORTICE
Width
152 cm
Height
49.5 cm
Diameter
152 cm
Weight
8.6 kg
