Weld On 4 Link Kit Brackets 2500lbs Bags Air Ride Suspension 2.75 Axle Mount

Name: Weld On 4 Link Kit Brackets 2500lbs Bags Air Ride Suspension 2.75 Axle Mount
Brand: MAXPEEDINGRODS
SKU: GG250804A621
Price: 231 GBP
Availability: InStock

~~£323.00~~

£20Offered

To be applied on the payment page

Offer valid today only.

Sold by maXpeedingrods GB

Product information

Description

General description

The Weld On 4 Link Kit Brackets are designed for universal rear triangulated 4 link suspension systems, suitable for most pickup trucks, hot rods, rat rods, or classic cars with a 2.75" axle tube. This kit includes two 2500 lbs air spring bags and rear air spring bag mounts, providing enhanced handling and a comfortable ride.

Technical specifications

Weight capacity: 2500 lbs per air spring bag

Air spring bag diameter: 6"

Extended height: 8"

Closed height: 2.75"

Top mounting holes: Approx. 1-3/4" from eye to eye

Bottom mounting hole: One center mounting hole

All mounting holes: 3/8"-16 UNC

4 link bar dimensions:

- Tubing outside diameter: 1.25"

- Tubing wall thickness: 0.156"

- Length of all four bars: 24.00"

Compatibility and accessories

Compatible with Ford F150/F250

Compatible with Ford pickup trucks (1948)

Compatible with Ford Ranger (1991)

Compatible with GMC Sierra

Compatible with Chevrolet Silverado

Compatible with Jeep Cherokee XJ

Compatible with Jeep CJ-7 4WD

Compatible with Jeep Wrangler TJ (1997)

Compatible with Dodge Ram 1500, 2500, 3500

Package includes:

- 4 x Heavy Duty Steel Bars

- 4 x Zinc Plated Steel Rod Ends with Urethane Bushings

- 2 x Steel Weld-On Triangulated Frame Mounts

- 2 x Steel Weld-On Lower Axle Tube Mounts

- 4 x Steel Weld-On Center Link Axle Mounts

- 2 x Steel Weld-On Side Frame Mounts

- 8 x Button Head Bolts with Nyloc Nuts

- 2 x Weld-On Lower Axle Bag Mount

- 2 x Weld-On Upper Frame Bag Mount

- 2 x Standard 2500 Single 1/2" NPT Port Air Spring Bags

Installation

Installation requires welding of the frame and axle mounts as per the specifications provided in the kit. Ensure proper alignment and secure all components for optimal performance.

Usage

This suspension kit is designed to improve handling and ride comfort for vehicles equipped with a 2.75" axle tube. It is ideal for both on-road and off-road applications.

Other information

The connecting rods will be shipped in either black or silver, randomly.

Please refer to the actual product received for final specifications.

Features

Brand
MAXPEEDINGRODS
Warranty
2 year(s)
Material
Metal
ManoMano Reference
ME91116733
MMID
738390002856
Product code
GG250804A621
EAN
6941689825109
