West Gothic TRV Angled Thermostatic Radiator Valve and Lockshield - Satin Brushed Black

Name: West Gothic TRV Angled Thermostatic Radiator Valve and Lockshield - Satin Brushed Black
Brand: WEST
SKU: GOTHIC-SB
Price: 94.95 GBP
Availability: InStock

Sold by Heat & Plumb

Product information

Description

General description

The West Gothic TRV Angled Thermostatic Radiator Valve is a complete pairing of one lock-shield valve and one wheel-head valve. Designed and manufactured using high-quality methods and materials, this product ensures durability and long-term use. It comes with a 5-year guarantee.

Technical specifications

Radiator Valves Type: Thermostatic

Position: Angled

Radiator Valve Connection Size: 1/2" BSP

Radiator Valve Pipe Size: 15mm

Radiator Valve Height: 135.5mm

Radiator Valve Width: 85mm

Radiator Valve Depth: 55mm

Weight: 0.69 Kg

Material: Brass

Colour: Satin Brushed Black

Style: Traditional

Brand: West

Manufacturer Part Number: GOTHIC-SB

EAN Barcode: 763769985437

Installation

This thermostatic valve can be installed on either the flow or return in any orientation. It is important to note that the TRVs should be installed on the flow rather than the return pipework of a radiator. Additionally, a system automatic bypass valve is required for all new installations and boiler upgrades to function correctly and avoid radiator hammer.

Usage

The West Gothic TRV is used in conjunction with a system automatic bypass valve, which is a specific building regulation requirement. All bi-directional TRVs from any manufacturer require the bypass valve to function correctly.

Other information

Supplied with a 2-year guarantee from the manufacturer.

Features

Brand
WEST
Warranty
2 year(s)
Material
Brass
Connection configuration
Male
Colour
Black
Pipe thread size
1/2" (15x21)
Height
135.5 mm
Weight
690 g
ManoMano Reference
ME54522710
MMID
564138799956
Product code
GOTHIC-SB
EAN
0763769985437
