X1 3/4" Painted Open Wedge Socket With Bolt And Pin - Grip Tail Wire Rope

You may also like

Compare with similar items

Product information

Description

General description

These X1 3/4" Painted Open Wedge Sockets with Bolt and Pin are designed for gripping wire rope across a wide range of applications. They effectively retain the rope's full strength while securely holding it in place, making them ideal for various lifting and towing tasks.

Technical specifications

  • Size: 3/4"
  • Breaking Load: 25 Ton
  • Product Codes and Dimensions:
  • SFWS10: A (11.9 MM), B (6.8 MM), C (75 MM), D (140 MM), E (20.7 MM), F (20 MM), G (21.7 MM), H (13.5 MM), Breaking Load (8 Ton)
  • SFWS13: A (14.5 MM), B (9 MM), C (104.8 MM), D (180 MM), E (26.2 MM), F (25 MM), G (25.7 MM), H (15.7 MM), Breaking Load (10 Ton)
  • SFWS16: A (18.2 MM), B (12 MM), C (123 MM), D (210 MM), E (30.6 MM), F (30 MM), G (32.5 MM), H (13.6 MM), Breaking Load (20 Ton)
  • SFWS20: A (21.8 MM), B (12.9 MM), C (148 MM), D (250 MM), E (35 MM), F (35 MM), G (37.5 MM), H (17 MM), Breaking Load (25 Ton)
  • SFWS26: A (29.6 MM), B (19.8 MM), C (192 MM), D (320 MM), E (49.9 MM), F (50 MM), G (51 MM), H (22.8 MM), Breaking Load (50 Ton)
  • SFWS28: A (29.4 MM), B (22.5 MM), C (200 MM), D (365 MM), E (55 MM), F (55 MM), G (61.2 MM), H (24.6 MM), Breaking Load (60 Ton)
  • SFWS32: A (34.1 MM), B (25.9 MM), C (220 MM), D (405 MM), E (63.8 MM), F (65 MM), G (64.1 MM), H (29.5 MM), Breaking Load (60 Ton)
  • Features

    • Brand
      SECUREFIX DIRECT
    • Material
      Two-material
    • Colour
      Multicolour
    • Pcs per pack
      1
    • Warranty
      1 year(s)
