4340 Connecting Rods Conrods for BMW 3 5 Series E36 E39 323i 523i M52 M52TUB25
You may also like
Compare with similar items
Product information
Description
Application
For BMW M50 M52 B25 TU 24V M52TUB25
For BMW E46 323i, 323Ci M52TUB25 1998 - 2000
For BMW E39 523i M52TUB25 1998 - 2000
For BMW E36/7 Z3 2.3i M52TUB25 1998 - 2000
Specification
- TÜV Certification Con Rods
- Type: Forged 4340 aircraft chrome moly quality steel for racing
- H-beam Conrods Quantity: 6 Pieces as showing in picture
- Bolts: Including ARP 2000 bolts
- Note: Extra cost for upgrading to ARP L19 bolts
- Bolts Size: ARP 2000 3/8" bolts
- Tolerance: Balanced to +/- 1 gram in set
- Piston Bolt Hole: +-4/1000mm
- Power: 600hp ~ 800hp per set
- Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
- Top acceleration: 9000rpm
- Warranty: 2 years warranty for any manufacturing defect
Dimensions
Center to center length: 140mm
Big end diameter: 48mm
Small end diameter: 22mm
Big end width: 21.9mm
Small end width: 21.9mm
Feature
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
Note
- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
Features
- BrandMAXPEEDINGRODS
- Width21.9 mm
- MaterialSteel
- Pcs per pack6
- Warranty2 year(s)
