General description
This electric winch is specially designed for vehicle recovery. It features a free spool clutch operated by a pull and turn knob, allowing the wire rope to be pulled out without using electric power. A tension plate reduces backlash and snaring when pulling out the wire rope. The winch also includes a mounting plate, a roller fairlead, and a wireless remote control. Equipped with a permanent motor, this device is suitable for intermittent duty applications.Technical specifications
- Max. line pull: 1360 KG
- Max. current: 145 Amp
- Motor: 1.2 HP, DC 12 V permanent magnet
- Gear ratio: 153:1
- Gearing: Differential planetary
- Wire rope length: 9 m
- Weight: 6.5 KG
- Dimensions: 285 x 105 x 105 mm (L x W x H)
- Drum diameter: 31.75 mm
- Control: Wire remote switch + wireless remote control switch (1 x 12V 23A alkaline battery not included)
- Includes mounting plate and roller fairlead
Installation
- Delivery includes: 1 x winch, 1 x mounting plate, 1 x roller fairlead, 1 x wireless remote control, 1 x wire remote control, 1 x hook with cable, power cable, and mounting accessories such as screws and nuts.
Usage
- Do not let children play with the appliance.
- This is not a toy.
- Only technically skilled operators should use the tool.
- Wear personal protective equipment before using this product.
- Keep children and bystanders away while operating a power tool.
