Published on 01/07/2024, FranceProduct meets my expectations, only one downside, I thought I would receive the corresponding nut with it.
1/5
2 Pcs 6mm Tube OD x 1/8 BSP Male Straight Push To Connect Fittings (PC6-01)
Sold by B2C Agro Top Garden GmbH
You may also like
Compare with similar items
Product information
Description
General descriptionThe 2 Pcs 6mm Tube OD x 1/8 BSP Male Straight Push To Connect Fittings (Model PL6-01) are designed for efficient and reliable connections in pneumatic systems. These fittings are made from premium quality plastic and brass, ensuring durability and a long service life. They are ideal for connecting pipelines and various pneumatic components, providing a quick and easy assembly process.Technical specificationsModel: PL6-01Tube Outer Diameter: 6mmBSP Thread Size: 1/8Working Pressure Range: 0-1 MPAWorking Temperature: 0-60°CApplicable Pipe Materials: PU/PA/PE/PVCInstallationWrap the provided raw material tape around the threaded connection to prevent leakage.Insert the tube downward into the fitting after pressing the blue joint.Screw on the threaded end to secure the connection.Ensure the cut surface of the pipe is vertical and smooth for optimal sealing.After installation, pull the pipe to confirm it is securely connected.UsageUsed for connecting various pneumatic tools and components.Not suitable for environments with excessive dust or particles.Limited to air or vacuum applications only.Other informationProduct includes 2 pcs of PC adapters.The blue joint allows for 360-degree rotation for flexible installation.Do not apply additional external loads (bending, twisting, or pulling) to the pipe port to avoid damage or leakage.
Features
- BrandLINGHHANG
- Warranty2 year(s)
- MaterialBrass
- Pcs per pack2
- Connection configurationMale
- Outer diameter6 mm
- Inside diameter6 mm
- WaterproofYes
- Pipe thread size1/8" (5x10)
- Fitting shapeStraight coupling
- Length20 mm
- Weight100 g
- ManoMano ReferenceME84729953
- MMID227882712283
- Product codeAG018216HJ
- EAN8746798599556
Advice from
Air tools and accessories buying guide
Air compressors are no good without the accessories needed to run them. Tools and components like tyre inflators, air spray guns, air fittings and air hoses should be chosen to match your air compressor in terms of pressure rating and flow rate. Got a few small jobs to tackle? An air compressor kit will get you far!
