Union 2134E 5-Lever BS Mortice Deadlock in Satin Chrome Finish, 79.5mm (3-inch) with Visible Keyhole

Description

• This British Standard 5-lever mortice deadlock is designed for external timber doors hinged on either side. Suitable for doors up to 54mm thick, it features a deadbolt that can be locked or unlocked with a key from either side, providing secure locking. The deadbolt is 20mm long, offering positive deadlocking and enhanced resistance against forced entry. The lock includes anti-pick, anti-saw, and anti-drill security features, with a chamfered bolt design that improves performance under side load testing and makes drilling attacks more difficult. Supplied with a matching covered escutcheon for a neat finish. The lock is recommended by insurance companies, kitemarked to BS3621: 2007, and approved by the police Secured by Design initiative. It comes with a 15-year guarantee.

Specifications

• Material: Brass deadbolt with hardened steel rollers
• Case size: 79.5mm x 71.5mm (3 inches)
• Backset: 57.5mm (distance from door edge to center of keyhole)
• Rebate Kit: 2954 (available in 13mm, 19mm, or 25mm)
• Keys: Supplied with 3 nickel-plated steel keys
• Key blank number: KB430
• Security level: 2-5 levers (higher number indicates greater security)

Compatibility and Accessories

• Compatible with external timber doors up to 54mm thick
• Rebate Kit 2954 for different door thicknesses (13mm, 19mm, 25mm)
• Matching escutcheon for a cohesive appearance

Installation

• Designed for mortice installation in timber doors
• Case size: 79.5mm x 71.5mm, with a backset of 57.5mm
• Supplied with necessary hardware and rebate kit for proper fitting

Usage

• Lock or unlock the deadbolt with a key from either side of the door
• Ideal for securing external doors requiring high security
• Use in conjunction with compatible door handles and strike plates for optimal performance

Other Information

• Recommended by insurance companies and police Secured by Design
• Covered by a 15-year guarantee
