AREBOS Hydraulic Car Ramp
- Adjustable ramp of 10.63 - 14.76 in (270 - 375 mm) for numerous cars
- Sturdy steel construction to CE standard
- With hydraulic jack with safety / overload valve
- Secure bolt for securing the raised vehicle
- Entry width to 9.65 in (245 mm)
If hobby craftsmen have no space for a professional lifting platform in their own garage, or if the floor is not suitable for fastening, it is worthwhile to use this drive-on ramp with hydraulic jack. This car ramp does not have to be fastened or anchored, but is used exactly where it is needed. It can then be stowed away to save space, for example in the garage or basement.
Practical & stable
The access ramp consists of a stable steel construction. The platform can be raised continuously using the manual hydraulic jack.
Due to the robust construction, each ramp has a load capacity of 2 tons according to CE standards.
The platform can be fixed with two safety bolts, which are used for safety. Chained to the frame structure, these are not lost.
Compatible with a wide variety of vehicles
The 400 x 270 mm platform ensures that the vehicle stands securely, while the 1150 x 325 mm footprint gives the ramp a firm footing.
- Capacity: max. 4409 lbs (2000 kg)
- Ramp height Starting position: 10.63 in (270 mm)
- Drivable width: up to 9.65 in (245 mm)
- Capacity hydraulic jack: max. 4409 lbs (2000 kg)
- Height adjustable: from 10.63 - 14.76 in (270 - 375 mm)
- Dimensions: 14.28 x 12.8 x 10.63 in (1150 x 325 x 270 mm)
- Platform size: 15.75 x 10.63 in (400 x 270 mm)
- Material: Steel
- Colour: Red
- Weight: 92.6 lbs (42 kg)
- Brand: AREBOS
- Delivery: 2x access ramp, 2x hydraulic cylinders, 1x instruction manual
