General description
The 360° 4D 16 Lines Laser Level is a versatile self-leveling tool designed for precise interior construction layout and calibration. It emits visible horizontal, vertical, and diagonal laser lines, allowing for accurate measurements and alignment. This laser level is suitable for various applications, including floor tile layout, wallpapering, wainscoting, finish carpentry, and wall stud layout.Technical specifications
- Laser Class: Class 2
- Output Power: <1mW
- Wavelength: 532 nm (green)
- Automatic leveling range: ±3°
- Horizontal/Vertical Accuracy: ±0.2 mm/10 m
- Working distance: 25 m
- Operating temperature: -5℃ to 50℃
- Waterproof Level: IP54
- Dimensions: 130*102*134 mm / 5.12*4.02*5.28 in
- Item Weight: 1485 g / 3.27 lbs
- Package Weight: 1649 g / 3.64 lbs
Compatibility and accessories
- Includes 2 rechargeable lithium batteries (2400mAh each)
- Battery Charger
- Tripod Base
- Wall Bracket
- Iron Board
- Lifting Platform
- Remote Control
- 1/4 inch to 5/8 inch thread adapter
- Carry Bag
- Guideline
Installation
The laser level can be easily mounted using the strong magnetic wall mount or the included tripod base. It features a T-shaped bracket with a rotating base for 360° adjustments and a fine-tuning mechanism for precise targeting.
Usage
This laser level is designed for both indoor and outdoor use. It features a touch button design for easy operation, allowing users to switch between horizontal, vertical, and tilt lines. The brightness of the laser can be adjusted based on working conditions. Additionally, it can be controlled via a mobile app through Bluetooth for added convenience.
