Product information

Description

General description

This hydraulic plate punching tube tool features a maximum opening force of 90KN and includes six different dies, allowing it to effectively stamp metal sheets ranging from 0.9 to 2.4 inches. Its lightweight design and ergonomic handle facilitate easy handling and operation, making it an ideal tool for construction sites.

Technical specifications

Model: TPA-8

Color: Gold, Silver

Material: Metal

Stroke: 22mm / 0.87 inch

Punching Range: 22.5-60.8mm / 0.9-2.4 inch

Punching Conditions: Opening a Low Carbon Steel Plate of 3.2mm / 0.12 inch or less

Maximum Opening Force: 90KN

Mold Configuration: Φ22mm / 0.9 inch, 27.5mm / 1.1 inch, 34mm / 1.3 inch, 43mm / 1.7 inch, 49mm / 2 inch, 60.8mm / 2.4 inch

Fastening Bolts Diameter: About 19mm / 0.75 inch, 11mm / 0.43 inch

Oil Capacity: 60ml / 0.01 gal / 2 Oz

Traction Bolt Type: 7/16 x 3/4", 3/4 x 3/4"

Ambient Temperature: -20-40℃ / -68-104℉

Product Weight: 4.5kg / 9.9lbs

Compatibility and accessories

Includes 1 Hydraulic Plate Punching Tube Tool

6 Punch Molds

2 Drawing Studs

1 Seal Kit

1 Plastic Tool Box

1 English Manual

Installation

Please read the manual completely before installation and use, paying particular attention to the safety instructions included.

Usage

Suitable for punching metal sheets of 0.9-2.4 inches.

The smooth surface allows for easy cleaning; simply wipe with a wet cloth and dry.

Other information

Plastic Tool Box for storing small accessories to avoid loss.

Top handle for convenient carrying.

Sealing Rings to prevent oil leakage.

Features

Brand
CNCEST
Weight
4.5 kg
Material
Metal
Warranty
1 year(s)
ManoMano Reference
ME95966247
