General description
The ANNKE 4K PoE Camera System is a comprehensive video surveillance solution featuring 8 dome PoE cameras and a 4TB HDD. It delivers ultra-clear 3K video resolution (3072x1728@20fps) with a 16:9 aspect ratio, making it ideal for modern displays. The system is designed for easy installation and management, providing powerful features for home security.
Technical specifications
- Camera Sensor: 1/3" Progressive Scan BSI CMOS
- Max Resolution: 3K (3072x1728), 16:9 aspect ratio
- Video Compression: H.264+/H.264/H.265/H.265+
- Max Recording Resolution: Up to 8MP (3840 x 2160)@30fps
- Max Playback Resolution: Up to 8MP (3840 x 2160)@30fps
- Max Playback Channel: 8CH
- Operating Power: DC 48 V
- Power Consumption: ≤10 W (Without HDD and PoE)
- Dimensions (NVR): 12.4” x 9.4” x 1.9” (315 x 240 x 48 mm)
- Weight (NVR): 2.2 lbs (1 kg)
- Camera Dimensions: 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")
- Camera Weight: 0.6 lb (270 g)
Compatibility and accessories
- Includes 8 dome PoE cameras
- 4TB HDD for storage
- Power adapter and user manuals for both NVR and cameras
Installation
The ANNKE PoE NVR is designed for plug-and-play installation. Simply connect the PoE IP cameras to the NVR using Ethernet cables for easy setup and management.
Usage
This surveillance system is suitable for both indoor and outdoor use, providing clear day and night vision with features such as smart dual-light technology for enhanced night imaging. Users can monitor their property remotely via the "Annke Vision" app, allowing for live video access from smartphones, tablets, or PCs.
Other information
