General description
The ANNKE 8 × 3K PoE Cameras H.265+ Support IP67 Weatherproof CCTV Camera Kit is a comprehensive 16-channel PoE security system featuring a 4TB HDD. This kit includes eight high-definition cameras capable of delivering ultra-clear 3K video resolution (3072x1728@20fps) with a 16:9 aspect ratio, ensuring that every detail is captured accurately. The system is designed for easy installation and management, making it an ideal choice for enhancing home security.
Technical specifications
- Camera Image Sensor: 1/3" Progressive Scan BSI CMOS
- Max Resolution: 3K (3072x1728)
- Video Compression: H.264+/H.264/H.265/H.265+
- Max Recording Resolution: Up to 8MP (3840 x 2160)@30fps
- Max Playback Resolution: Up to 8MP (3840 x 2160)@30fps
- Max Playback Channel: 8CH
- Operating Power: DC 12 V± 25%, max. 6 W; PoE (802.3af), max. 7.5 W
- Dimensions (NVR): 12.4” x 9.4” x 1.9” (315 x 240 x 48 mm)
- Weight (NVR without HDD): 2.2 lbs (1 kg)
- Camera Dimensions: Ø121.4 mm × 97.7 mm (Ø4.8" × 3.8")
- Camera Weight: Approx. 550 g (1.2 lb.)
Compatibility and accessories
- Includes 8 PoE IP cameras
- 4TB HDD for storage
- Power Adapter
- User's Manual for NVR
- User's Manual for Camera
Installation
The ANNKE system is designed for easy plug-and-play installation. Simply connect the PoE IP cameras to the NVR using Ethernet cables for straightforward setup and management.
Usage
This security system is ideal for monitoring residential and commercial properties. Users can access live video feeds remotely via the "Annke Vision" app, allowing for real-time surveillance from smartphones, tablets, or PCs. The system supports customizable motion detection zones to minimize false alerts and enhance security.
Other information
- IP67 weatherproof rating ensures durability in harsh conditions
- Smart Dual-Light technology for enhanced night vision
- Built-in microphone for audio recording
- Supports on-board storage up to 256 GB (SD card slot)
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Lightning protection up to 2000 V
