General description
ANNKE 8CH CCTV Kit is a comprehensive security camera system designed for effective remote monitoring. It features a 1TB HDD for storage, ensuring you can record and playback high-quality footage. The system includes advanced features such as full-color night vision, smart waterproof design, and remote access capabilities, making it suitable for both indoor and outdoor use.Technical specifications
- Video Compression: H.264+/H.264/H.265/H.265 Pro+
- Video Input: 8CH Analog HD/Analog + 2CH IP Video (up to 12 channels in IP enhanced mode)
- Video Output: HDMI and VGA Up to 1080P
- Audio Input: 1-ch RCA, 8-ch via coaxial cable
- Audio Output: 1-ch RCA
- Supported Camera Types: HD TVI, AHD, CVI, CVBS, IP Video Input (up to 6MP)
- Max Playback Channel: 8-ch
- Total Bandwidth: 96Mbps
- Operating Power: DC12V, ≤ 12W (without HDD)
- Working Temperature: -14 °F – 131 °F / -10 °C – 55 °C
- Dimensions (W x H x D): 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weight (without hard disk): ≤ 1 kg (2.2 lb)
Camera
- Image Sensor: 2MP CMOS
- Video Resolution: 1920 (H) X 1080 (V)
- Lens: 2.8 mm
- Min. Illumination: 0.001 Lux@(F1.0, AGC On), 0 Lux with White Light
- Angle of View: horizontal FOV: 102°, vertical FOV: 54°, diagonal FOV: 121°
- Light Distance: Up to 65 ft/20 m
- Weatherproof Rating: IP66
- Dimensions: 82.65 mm × 91.0 mm × 69.16 mm (Ø 3.25" × 3.58" × 2.72")
- Weight: Approx. 238.5 g (0.53 lb)
Usage
- Remote monitoring via smartphone and tablet with a free viewing app.
- Real-time push notifications and email alerts for suspicious movements.
- Effective for both day and night surveillance with full-color night vision.
